Operating instructions for the AGV trolley

Before getting familiar with using the AGV car, please keep in mind the following precautions:

1. Before starting the AGV car, please pay attention to whether the car is in the middle of the guide line. If the position is not correct, please turn off the power of the car and push the car to the middle of the guide line before starting the car. The car is divided into the front and the rear of the car. The front of the car is equipped with the LCD screen, and the other side is the rear of the car. The start of the car must ensure that the front and rear of the car are online, that is, the guide line is in the middle of the front and rear of the car. The left and right deviations can be plus or minus 10CM. After the car starts, it will automatically adjust the front end of the car to make it in the position.

2. Before starting the AGV car, please check if the red stop button at the top of the car is pressed. If it is in a tight stop state, rotate the stop button to make it pop up.

3. Rotate the key of the roof to start the power supply of the car. If you hear a short sound of “drop” and a blue welcome screen appears on the LCD, it indicates that the car has started successfully. If you hear the long sound of “Drip--”, it means that the car is not starting properly. Please turn the key back to the original position, turn off the power of the car and wait for 5 seconds to restart the car until the startup is successful. If the start is not successful for more than 3 consecutive times, please charge the car as soon as possible.

4. After the AGV car starts normally, the two yellow parking lights turn off briefly for 3 seconds and then go out. A blue welcome screen appears on the LCD screen, and the car enters the internal system self-test process. After a brief self-test, the car enters normal operation and waits for the operator to proceed to the next step.

5. AGV car internal lead-acid battery can support continuous operation for 6 hours, if the reading address card is not successful in normal operation, or the car is not successful from the stop state, please charge the car as soon as possible, please guarantee 8 hours charging time .

6. When charging the AGV car, you need to take the stop button and turn the key switch counterclockwise to turn off the car power. Turn on the power plug of the charger, plug the charger into the charging socket at the rear of the car, and turn on the charger. The green charging light on the top of the car lights up, indicating that the charging process is normal. Check the status of each knob on the charger. The charging voltage must be 24V, and the charging current should be rotated clockwise to the maximum position. After charging for 8 hours, please check the ammeter pointer reading on the charger. When the pointer reading is less than 1A, it means the charging process is nearing the end and the charger can be unplugged.
