The Two-dimension code navigation AGV is a product that is specially designed for simple and light material handling in the factory. It uses inertial QR code to navigate the faster storage robot. According to the order, the shelves where the goods are located are transported from the huge warehouse storage area to the employee processing area, which greatly improves the efficiency of the warehouse. The Two-dimension code navigation AGV can improve the storage capacity of nearly 50%.
The Features of Two-dimension code navigation AGV:
1. AGV positioning is accurate, small and flexible, the speed can reach 80m / min;
2. laying and changing the path is also easier;
3. easy to control communication, no interference to sound and light.
4. non-magnet guide line on the ground;
5. less space requested;
6. high accuracy and speed, free mapping and routing;
7. compatible with WMS for real time material position and situation;
Two-dimension code navigation AGV Parameter:
|
Weight
|
150kg | 180kg |
|
Payload
|
500kg
|
1000kg |
|
Dimension
|
906*710*300mm
|
1100*880*300mm |
|
Max Speed
|
2m/s
|
1.2m/s |
|
Guidance Type
|
Visual+2 Dmimensional Code |
|
|
Obstacle Avoidance
|
Laser Radar
|
|
|
Communication Mode
|
WiFi·Wifi
|
|
|
Stop Accuracy
|
<10mm
|
|
|
Gap
|
<10mm
|
|
|
Lifting Height
|
≥52mm
|
|
|
Full Lifting Time
|
≤4s
|
|
|
Battery Capacity
|
40AH
|
|
|
Working Hour
|
8 Hours for Full Loaded, It Can Meet Requirements of Continuously Working 24 Hours
|
|
|
Charge
|
Automatic Charging,Manual Charging,Battery Replacing
|
|
|
Work Status Light
|
Front / Rear
|
|
|
Emergency Switch
|
Front / Rear
|
|
|
Quick Start Button
|
Two Sets Both in Front / Rear
|
|
|
Charging Method
|
anual Charging or Automatic Charging
|
|
The 2D barcode scanning module fully utilizes its own core barcode recognition function. According to the two-dimensional code reading in the motion state, Danbach AGV needs to know the angle and other information when reading the code. In particular, the industrial two-dimensional code scanning module is introduced, that is, industrial vision can achieve two-dimensional on the assembly line. The code is read, thereby improving the scanning performance of the AGV, thereby greatly improving the work efficiency.
Danbach's industrial Two-dimension code camera module combines advanced intelligent image algorithms, chip design and manufacturing processes. It is equipped with a world-class 2D barcode reading engine to quickly read the maximum brightness and various types of film. Screen barcodes can be well integrated into a variety of automatic guided AGV, machine vision inspection systems, production line equipment, industrial inspection.
